S501001018V Tork Compressor Solenoid 2/2 1/4 NC

S501001018V

Aplication: Compressor , 0,5 to 16Bar, Orifice 1.8mm 10 a 60°C, ED100%,  IP65

Volts
$47.00
Quantity
Product available with different options

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description
GENERAL DETAILS

S5010 Series ( TORK-GK) Compressor Solenoid Valves

Application : Air, hot and oily air
Size  1/8"…….1" BSP (on request NPT)
Pressure 0,5 bar…16 bar
Tube and internal part : Stainless Steel
Body Brass
Seal : VITON
Temperature .-10°C…160 °C
Position Normally Closed
Coil Voltage 230V, 110V , 48V, 24V , 12V  AC ; 110V , 48V , 24V , 12 V DC
Protection Class : IP65 and Exproof models



SPECIFICATION

Valve Type / Order No Connection Size Orifice Size (mm) Pressure (bar) KV  lt/ min Fluid Temperature Seal Weight (kg)
Min  Max Min Max
S5010.00.018 1/8" 1,8 0 16 1,6 -10 160 VITON 0,29
S5010.01.018 1/4" 1,8 0 16 1,6 -10 160 VITON 0,28
S5010.02 3/8" 12,5 0,5 16 48 -10 160 VITON 0,68
S5010.03 1/2" 14,5 0,5 16 70 -10 160 VITON 0,71
S5010.04 3/4" 17 0,5 16 85 -10 160 VITON 0,8
S5010.05 1" 17 0,5 16 90 -10 160 VITON 0,97
Product Details
S501001018V
