FEATURES/BENEFITS
• Metal conduit housing option
• Robust 316 SS oil filled sensor
• Compact design
Â
APPLICATIONS
• Compressors
• Pumping systems
• Irrigation equipment
• Hydraulic
• Industrial process monitoring
Specifications
- Service:
- Compatible gases and liquids.
- Wetted Materials:
- Type 316L SS.
- Accuracy:
- >626: 0.25% FS; 0.20% RSS;
628: 1.0% FS; 0.5% RSS;
626 Absolute Ranges: 0.5% FS; 0.35% RSS.
(Includes linearity, hysteresis, and repeatability).
- Temperature Limit:
- 0 to 200°F (-18 to 93°C).
- Compensated Temperature Range:
- 0 to 175°F (-18 to 79°C).
- Thermal Effect:
- ±0.02% FS/°F. (includes zero and span).
- Pressure Limits:
- See Catalog page.
- Power Requirements:
- 10-30 VDC (for 4-20 mA, 0-5, 1-5, 1-6 VDC outputs); 13-30
VDC (for 0-10, 2-10 VDC outputs); 5 VDC ±0.5 VDC (for 0.5-4.5 VDC ratio-metric
output). - Output Signal:
- 4-20 mA, 0-5 VDC,1-5 VDC, 0-10 VDC, or 0.5-4.5 VDC.
- Response Time:
- 300 ms.
- Loop Resistance:
- 0-1000 Ohms max. R max = 50 (Vps-10) Ohms (4-20 mA
output), 5K Ohms (0-5, 1-5, 1-6, 0-10, 2-10, 0.5-4.5 VDC output). - Stability:
- 1.0% FS/year (Typ.).
- Current Consumption:
- 38 mA maximum (for 4-20 mA output); 10 mA maximum
(for 0-5, 1-5, 1-6, 0-10, 2-10, 0.5-4.5 VDC output); 140 mA maximum (for all
626/628/629-CH with optional LED). - Electrical Connections:
- Conduit Housing (-CH): terminal block; 1/2″ female NPT conduit. General Purpose Housing (-GH): cable or DIN EN175801-803-C.
- Process Connection:
- 1/4″ male or female NPT and BSPT.
- Enclosure Rating:
- NEMA 4X (IP66).
- Mounting Orientation:
- Mount in any position.
- Weight:
- 10 oz (283 g).
- Agency Approvals:
- CE.
